For Juniper, EX-SFP-GE10KT13R14/T14R13 1310/1490nm 10KM BIDI SFP LC Transceiver

ONE PAIR PRICE IS 40DOLLARS (include:EX-SFP-GE10KT13R14 : TX1310/RX1490 / EX-SFP-GE10KT14R13: TX1490/RX1310)

Product Condition:

NEW

Features

Dual data-rate of 1.25Gbps/1.063Gbps operation
Compliant with SFP MSA and SFF-8472
Internal Calibration or External Calibration
Compatible with SONET OC-24-LR-1
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard : 0 to +70°C

Applications

Gigabit Ethernet
Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems

Description

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of
1.25Gbps/1.0625Gbps and 20km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a
trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety
requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further
information, please refer to SFP MSA.

Warranty:

We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials. All the optical transceivers have been through functional testing and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.
